1-3/8" Low Peak 4-Way Canopy Fitting - Eave

1-3/8" Low Peak 4-Way Canopy Fitting - Eave - Gray Powder Coated

4WAY138-LPE

View Detailed Images 5 View Detailed Images 5 View Detailed Images 5 View Detailed Images 5 View Detailed Images 5

Shipping Estimate

Below is a shipping matrix displaying what your cost of shipping will be for this item to the listed destinations utilizing the listed shipping methods:

	Miami33125	Cincinnati45202	Kansas City66101	Denver80201	Seattle98101
FedEx Home Delivery®	$15.50	$15.50	$15.50	$15.50	$16.01
FedEx SmartPost®	$16.75	$22.63	$23.38	$24.79	$26.52
USPS Priority Mail®	$11.67	$14.50	$16.30	$18.95	$22.45
USPS USPS Ground Advantage^TM	$10.27	$11.80	$12.90	$14.90	$17.65

Description
Specifications
Send to Friend

Product Summary

The 1-3/8" Low Peak 4-Way Canopy Fitting - Eave - Gray Powder Coated is designed to be used to form the middle sections of the eave (ridge) of a low gable peak canopy frame. The angle of the corner angle along the eave formed by this fitting is 102 degrees (rise angle of 12 degrees). At this angle, the canopy rafters will rise at a rate of 2.5" / linear foot. These fittings are perfect for applications where the desired roof on the canopy is as close to flat as possible, but still has a slight angle for runoff. Our gray canopy fittings are crafted from 16 gauge powder coated steel with fully welded corners and connections.

Application(s)

Forms the middle sections of the eave of a low gable peak canopy frame.

Also forms the middle sections of the eave of a low gable sloped roof (lean-to) canopy frame.

Low Peak Angle

The angle of the corner angle along the eave formed by this fitting is 102 degrees (rise angle of 12 degrees)

Features

Extremely durable gray powder coated finish to resist rust and corrosion

Forms the middle sections of the eave of a low gable peak canopy frame or sloped roof (lean-to) canopy frame

Designed for use with 1-5/16" outer diameter pipe

Outer Diameter (OD): 1-1/2"

Inner Diameter (ID): 1-3/8"

Leg Length: 4-1/4"

Peak Angle: 156º

Eave Angle: 102º

Thickness: 16 gauge
