1-3/8" Low Peak 4-Way Canopy Fitting

1-3/8" Low Peak 4-Way Canopy Fitting - Slope

4WAY138-LPS

View Detailed Images 4 View Detailed Images 4 View Detailed Images 4 View Detailed Images 4

Shipping Estimate

Below is a shipping matrix displaying what your cost of shipping will be for this item to the listed destinations utilizing the listed shipping methods:

	Miami33125	Cincinnati45202	Kansas City66101	Denver80201	Seattle98101
FedEx Home Delivery®	$16.51	$16.51	$16.51	$17.20	$17.86
FedEx SmartPost®	$17.87	$24.15	$24.73	$26.44	$28.31
USPS Priority Mail®	$12.50	$15.55	$17.80	$20.05	$23.10
USPS USPS Ground Advantage^TM	$10.85	$12.45	$13.60	$15.70	$18.60

Description
Specifications
Send to Friend

Product Summary

The 1-3/8" Low Peak 4-Way Canopy Fitting - Slope is designed to be used to form the middle sections of the peak of a low gable sloped roof (lean-to) canopy frame. The angle of the corner angle along the eave formed by this fitting is 102 degrees (rise angle of 12 degrees). At this angle, the canopy rafters will rise at a rate of 2.5" / linear foot. These fittings are primarily used to create a sloped roof, lean-to canopy structure along side an existing building or canopy frame. Our canopy fittings are crafted from 16 gauge galvanized steel with fully welded corners and connections.

Application

Forms the middle sections of the peak of a low gable sloped roof (lean-to) canopy frame.

Low Peak Angle

The angle of the corner angle along the eave formed by this fitting is 102 degrees (rise angle of 12 degrees)

Features

Galvanized steel construction to resist rusting

Designed for use with 1-5/16" outer diameter pipe

Outer Diameter (OD): 1-1/2"

Inner Diameter (ID): 1-3/8"

Leg Length: 4-3/8"

Peak Angle: 78º

Eave Angle: 102º

Thickness: 16 gauge
